WEIGHT
Camper (unloaded): 840 lbs | 381 kg
GVWR: 1650 lbs | 748.42 kg
Carrying Capacity: 810 lbs | 367.41 kg
Equipment Rack Capacity: 160 lbs | 72.57 kg
DIMENSIONS
Exterior (compact): 140 x 75 x 52 in | 3.56 x 1.91 x 1.32 m
Exterior (expanded): 140 x 75 x 80 in | 3.56 x 1.91 x 2.03 m
Exterior (camper): 154 x 124 x 105 in | 3.91 x 3.15 x 2.67 m
Gear Deck (compact): 84 x 48 x 17 in | 2.14 x 1.22 x 0.43 m
Gear Deck (extended): 84 x 48 x 48 in | 2.14 x 1.22 x 1.22
Interior Floor Dimension: 84 x 48 in | 2.13 x 1.22 m
Standing Height (camper): 77 in | 1.96 m
Storage Box: 9 cu ft | .23 cu m
HITCH REQUIREMENTS
Hitch Size: 1-1/4 or 2 in
Ball Size: 2 in
Ball Height (measured from ground to center of ball): 17″
